Hydraulic Link Clamp Carbon Steel Body Surface Chrome Plated Strong Structure

Name: Hydraulic Link Clamp Carbon Steel Body Surface Chrome Plated Strong Structure
Brand: Jiayan
Price: 1 USD

China Hydraulic Link Clamp Carbon Steel Body Surface Chrome Plated Strong Structure wholesale

Brand Name : Jiayan

Model Number : CHLC

Certification : ISO9001:2008

Place of Origin : Dongguan China

MOQ : 1 set

Payment Terms : L/C, T/T, Western Union

Supply Ability : 400 sets per week

Delivery Time : 7 days

Packaging Details : poly bag and carton box

Material : Carbon Steel

Max. operating pressure : 70 kgf/cm2

Min. operating pressure : 10 kgf/cm2

Acting Type : Double Acting

Fluid : Filtered oil

Work Temperature : -10~+70C

Warranty : 1 year (change for free)

Contact Now

Hydraulic Link Clamp Carbon Steel Body Surface Chrome Plated Strong Structure for Stable Performance

Features:

1.The clamping mechanism of this type hydraulic cylinder is the principle of lever.

The piston is pushed out in clamping state. The clamping force is larger than the swing

clamp cylinder. The main mechanism parts are installed outside the cylinder and easy to

maintain.
2.The cylinder body and clamping mechanism materials are made of carbon steel for

mechanical construction, which is sturdy and durable and has a long service life.
3.The piston material is chrome-plated with 45 steel heat treatment surface.
4.When the pressure plate needs to increase the length, please do not exceed 1.5 times the

original length.

Specification

Bore of Cylinder(mm)	Φ25	Φ32	Φ40	Φ50	Φ63
Bore of Piston(mm)	Φ18	Φ20	Φ22.4	Φ28	Φ35
Total stroke(mm)	25	25	30	34	40
Pressure area push cm²	4.91	8.04	12.57	19.63	31.17
Theoretical Clamping Force 30 kg/cm²	116kgs	190kgs	288kgs	453kgs	701kgs
Fluid	Filtered oil
Range of temperature	-10~+60°C
Max Pressure	70kg/cm²
Range of pressure	10-50kg/cm²
Acting type	Double acting

Hydraulic Link Clamp Carbon Steel Body Surface Chrome Plated Strong Structure

Pls contact us for more details on the sizes of this type link clamp cylinder.
