High Force Air Powered Swing Clamps , Destaco Pneumatic Clamps Block Type

Name: High Force Air Powered Swing Clamps Destaco Pneumatic Clamps Block Type
Brand: Jiayan
Price: 1 USD

Brand Name : Jiayan

Model Number : PSB

Certification : ISO9001:2008

Place of Origin : Dongguan China

MOQ : 1 set

Price : Negotiable

Payment Terms : L/C, T/T, Western Union,Paypal

Supply Ability : 1000 sets per week

Delivery Time : 7 days

Packaging Details : poly bag and carton box

Material : Aluminum

Power : Pneumatic

Structure : Piston Cylinder

Maximum Stroke : 31mm

Bore of Cylinder : 40mm

Diameter of Piston : 16mm

Contact Now

Air Driven Rotary Swing Clamp Block Type Screw Mounting Max. Clamping Force 140kgs

Product Introduction

1.Delicate design ,compact structure ,light weight , long life span and high clamping force make it a perfect clamp.
2.The sensor is available for this kind of swing clamp.
3.Upper installation , bottom installation or side installation.
4.When increasing length of clamping arm is required, be sure not to exceed 1.5 times of the original length.

Specification

Bore of Cylinder (mm)	25	32	40	50	63
Dia. of Pison	14	16	16	20	20
Swing stroke (mm)	13	16	15	17	15
Clamping stroke	14		15
Pressure area pull/push cm ?2;	3.37/4.9	6.03/8.03	10.56/12.56	16.48/19.62	28.01/31.15
Theoretical Clamping 5kg/ cm 2;	16kgs	30kgs	50kgs	80kgs	140kgs
Fluid	Filtered air
Max operation pressure	10kg/cm2;
Range of pressure (kg/ cm 2; )	4-7kg/cm2;
Rotating direction	Turn right or Turn left
Rotating angle	Standard angle 90°
Acting type	Double acting
