Home > Horizontal Toggle Clamp >

High Power Horizontal Toggle Clamp 20820 / Stainless Steel Toggle Clamps

Product Categories

Dongguan Jiazheng Hydraulic Technology Co, LTD

Contact Now

Name: High Power Horizontal Toggle Clamp 20820 Stainless Steel Toggle Clamps
Brand: Jiayan
Price: 1 USD

Brand Name : Jiayan

Model Number : 20820

Certification : ISO9001:2008

Place of Origin : Dongguan China

MOQ : 5 pcs

Price : Negotiable

Payment Terms : L/C, T/T, Western Union,PayPal

Supply Ability : 3000 pcs per week

Delivery Time : 7 days

Packaging Details : poly bag and carton box

Material : Cold Roll Sheet

Weight : 400g

Holding Capacity : 100kg

Bar Opens : 185 degree

Handle Opens : 60 degree

Warranty : 1 year

Contact Now

100kgs Holding Force Horizontal QuicK Release Toggle Clamp 20820 Horizontal or Vertical Mounting Base 317-U

Product Specification and features:

Material :Cold Roll Sheet

Weight :400g

Holding Capacity:100kg

Bar Opens:185 degree

Handle Opens:60 degree

Sheet metal steel
Zinc plated
Red vinyl hand grip
Neoprene tipped spindle assembly

BASE TYPE: Horizontal/Vertical
STYLE: Horizontal
TYPE: Standard

Application:

1.Install on jigs, tool fixtures, or movable bases
2.Complete with adjustable rubber pressure tips

High Power Horizontal Toggle Clamp 20820 / Stainless Steel Toggle Clamps

Product Tags:

horizontal handle toggle clamp
