SURS21, 475 lbs Force, Swing Clamp, Single-Acting, Right Turning, Upper Flange

Name: SURS21 475 lbs Force Swing Clamp SingleActing Right Turning Upper Flange
Brand: Jiayan
Price: 1 USD

Brand Name : Jiayan

Model Number : SURS21

Certification : ISO9001

Place of Origin : Dongguan China

Maximum Operating Pressure (psi) : 5,000

Minimum Operating Pressure (psi) : 500

Clamping Force (lbs) : 475

Stroke (in) : 0.65

Stroke Clamping (in) : 0.32

Mounting Style : Upper Flange

Return Type : Single-Acting

Rotation Direction : Right

Cylinder Effective Area Clamp (in2) : 0.12

Oil Capacity Clamp (in3) : 0.08

Maximum Oil Flow (in3/min) : 12

Standard Clamp Arm : CAS21

Weight (lbs) : 1

Contact Now

SURS21, 475 lbs Force, Swing Clamp, Single-Acting, Right Turning, Upper Flange

Description
Series : SU
Product Lines : Workholding Tools

1.Flexible design allows for manifold or threaded port connection
2.Low profile mounting style allows body to be below mounting surface
3.Simple mounting preparation and easy installation – 3 or 4 mounting bolts
4.Double oil connection – threaded port or manifold mount
5.Symmetrical rectangular flange design enables clamping at three sides of the cylinder
6.30, 45, and 60 degree swing angles available on request
7.The Enerpac upper flange swing clamps are designed for integrated manifold mounting solutions. Hydraulic connections are made through SAE or BSPP oil connection or the standard integrated O-ring ports.

Maximum Operating Pressure (psi)
5,000
Minimum Operating Pressure (psi)
500
Clamping Force (lbs)
475
Stroke (in)
0.65
Stroke Clamping (in)
0.32
Mounting Style
Upper Flange
Return Type
Single-Acting
Rotation Direction
Right
Cylinder Effective Area Clamp (in2)
0.12
Oil Capacity Clamp (in3)
0.08
Maximum Oil Flow (in3/min)
12
Standard Clamp Arm
CAS21
Weight (lbs)
1
