318kgs Push Pull Toggle Clamp 30607 30608 Forged Alloy Steel Base Destaco 607

Name: 318kgs Push Pull Toggle Clamp 30607 30608 Forged Alloy Steel Base Destaco 607
Brand: Jiayan
Price: 1 USD

China 318kgs Push Pull Toggle Clamp 30607 30608 Forged Alloy Steel Base Destaco 607 wholesale

Brand Name : Jiayan

Model Number : 30607 and 30608

Certification : ISO9001:2008

Place of Origin : Dongguan China

MOQ : 1 pc

Price : Negotiable

Payment Terms : L/C, T/T, Western Union,PayPal

Supply Ability : 2000 pcs per week

Delivery Time : 7 days

Packaging Details : poly bag and carton box

Material : Forged Alloy Steel Base

Weight : 700g

Holding Force : 318kgs

Handle Opens : 180 degree

Plunger Stroke : 41.3mm

Surface Treatment : Zinc-plated

Contact Now

Forged Alloy Steel Base Push Pull 30607 and 30608 Holding Force 318kgs Destaco 607 for metal processing

Product Specification and features:

Material:Forged Alloy Steel Base

Weight :700g

Holding Force :318kgs

Handle Opens :180 degree

Plunger Stroke :41.3mm

Surface Treatment :Zinc-plated

straight line action clamp with flange base mounting
700lbs Hold Capacity,1.54 lbs weight,1.62" plunger stroke
Complete with adjustable rubber pressure tips
Material : Metal, Plastic; Package : 1 x Toggle Clamp
cross reference destaco 607

318kgs Push Pull Toggle Clamp 30607 30608 Forged Alloy Steel Base Destaco 607

Product Tags:

push pull action toggle clamps

woodworking toggle clamps
