Name: Square Push Pull Hydraulic Cylinder Axial Front Manifold Type Rear Manifold Type
Brand: Jiayan
Price: 1 USD

Brand Name : Jiayan

Model Number : SDMA/SDMB

Certification : ISO9001:2008

Place of Origin : Dongguan China

MOQ : 1 set

Price : negotiable

Payment Terms : L/C, , T/T, Western Union, Paypal

Supply Ability : 300 sets per week

Delivery Time : 7 days

Packaging Details : poly bag and carton box

Material : Carbon Steel

Mounting Type : axial manifold type

Max Operation Force : 140kg/cm2

Min. Operation Force : 5 kg/cm2

flow rate : 8-100mm/sec

Acting Type : Double Acting

Warranty : 1 year (change new one for free)

Contact Now

Axial Front Manifold Type and Rear Manifold Type Push Pull Hydraulic Cylinder Simple Mounting Machine Cylinder

Ordering Code

CHTB - SDMA 32×20 N

1 2 3 4 5

1	Series	CHTB
2	Mounting type	SDMA:Axial front manifold type SDMB:Axial back manifold type
3	Bore of Cylinder	Φ20 , Φ25 , Φ32 , Φ40 , Φ50 , Φ63 , Φ80
4	Standard stroke	Please refer to the <stroke specification>
5	Rod end type	N: Female thread N W:Male thread W

Hydraulic Cylinder Stroke Specifications

Square Push Pull Hydraulic Cylinder Axial Front Manifold Type Rear Manifold Type

Pressure

Bores of Cylinde Dia.of Piston Area (cm2) OPERATION PRESSURE(kgf/cm2) Temperature

Square Push Pull Hydraulic Cylinder Axial Front Manifold Type Rear Manifold Type

CHTB Hydraulic Cylinder Axial manifold type SDMA/SDMB

Square Push Pull Hydraulic Cylinder Axial Front Manifold Type Rear Manifold Type
